140mm Fan to 100mm Duct Adapter
- Arrives in 2 to 7 business days Printed in Auckland. $10 shipping, free over $75
- 14-day faulty refund If it arrives broken or misprinted, we reprint or refund it
- Secure checkout Card payments handled by Stripe
- Material
- High-Detail Resin (8K)
- Colour
- Grey
- Weight
- ~33 g
- Express shipping
- $20
More information
140mm Fan to 100mm Duct Adapter
A simple, no-supports adapter that connects a standard 140mm fan to 100mm (4") ducting. Great for fume extraction, workshop ventilation, and general airflow projects.
🔧 What it's for
• Soldering / 3D printing fume extraction
• Workshop and garage ventilation
• Connecting a 140mm fan to flexible aluminium or PVC duct
• General airflow and cooling setups
📐 Specifications
• Fan side: 140 × 140 mm flange with standard mounting holes
• Duct side: 100 mm outlet
• Height: ~49 mm
• Smooth internal transition for minimal airflow loss
🖨 Recommended print settings
• Material: PLA or PETG (PETG if exposed to heat or sunlight)
• Layer height: 0.2 mm
• Walls: 3 perimeters
• Infill: 15–20%
• Supports: None — prints flat on the flange
• Orientation: 140mm flange flat on the build plate
🔩 Assembly
Mount the fan to the 140mm flange with standard fan screws, then slide your 100mm duct over the outlet and secure with a hose clamp or tape.
💬 Notes
Need a different fan or duct size? Drop a comment — happy to remix. If this was useful, a like or boost is hugely appreciated and helps me keep designing! 🙌
Design and description by Malmer , licensed CC-BY.
Frequently asked
How long does shipping take?
140mm Fan to 100mm Duct Adapter is printed to order. Lead time is typically 1-3 business days plus 1-4 days NZ shipping. Standard NZ shipping is $10, free over $75.
What material is this printed in?
By default this is printed in High-Detail Resin (8K) at 0.025 mm layer height on an MSLA resin printer. Custom material and colour swaps are available, just leave a note at checkout.
Can I get this in a different colour?
Yes. Every product can be printed in any of the resin colours we stock, or hand-painted on request. Leave a note at checkout or email [email protected].
Do you ship outside of New Zealand?
Currently New Zealand only. Australian shipping is coming.
Who designed this?
Designed by an independent sculptor and licensed for commercial printing. The original is linked on this page.
