Customizable M20 Cable Glands, Inserts, Plug and Gasket (12 & 15mm ID)
- Arrives in 2 to 7 business days Printed in Auckland. $10 shipping, free over $75
- 14-day faulty refund If it arrives broken or misprinted, we reprint or refund it
- Secure checkout Card payments handled by Stripe
- Material
- High-Detail Resin (8K)
- Colour
- Grey
- Weight
- ~73 g
- Print time
- ~4 h
- Express shipping
- $20
More information
Complete set of M20 cable glands for 12mm and 15mm inner diameters, including 2-7-wire inserts (1.5mm² & 2.5mm² versions), reducing inserts (3-13mm) and a gasket for reliable sealing. Also includes an M20 plug compatible with the gasket and 12mm cable gland nut. Perfect for junction boxes or similar applications. Three parts per cable gland: body, inner nut, and top nut. Durable and highly versatile!
Thank you very much 93djen for your work on this!
Works great with Makita 18V LXT Battery Extension.
Printer Settings
• Cable gland Material: PETG, ABS or PA (for strength & heat resistance). PLA may work but is less durable. • Insert & gasket Material: TPU or similar • Nozzle Size: 0.4mm or larger. • Layer Height: 0.2mm recommended. • Supports: None required. • Infill: >30% • Wall thickness: >1,2mm
Key Details
• Hole Size Required for M20 Cable Glands: 20-21mm diameter. • Includes inserts compatible with 12mm and 15mm cable glands.
Metric-Imperial Conversion Table
MetricImperial
Hole Size :>20mm>0.787 inches
Cable Gland Inner Diameter: 12mm0.472 inches
Cable Gland Inner Diameter: 15mm0.591 inches
Thread Length: 10mm0.394 inches
Wire gauge compatibility (1.5mm² / 2.5mm²)16 AWG / 14 AWG
Note on PG Cable Glands
M20 glands differ from PG13.5 in hole size requirements. M20 needs a 20mm hole, while PG13.5 requires a 21mm hole. meaning that this M20 cable glands can be used in junction boxes and similar designed for PG13.5
Design and description by Muffelkraft , licensed CC-BY-SA.
Frequently asked
How long does shipping take?
Customizable M20 Cable Glands, Inserts, Plug and Gasket (12 & 15mm ID) is printed to order. Lead time is typically 1-3 business days plus 1-4 days NZ shipping. Standard NZ shipping is $10, free over $75.
What material is this printed in?
By default this is printed in High-Detail Resin (8K) at 0.025 mm layer height on an MSLA resin printer. Custom material and colour swaps are available, just leave a note at checkout.
Can I get this in a different colour?
Yes. Every product can be printed in any of the resin colours we stock, or hand-painted on request. Leave a note at checkout or email [email protected].
Do you ship outside of New Zealand?
Currently New Zealand only. Australian shipping is coming.
Who designed this?
Designed by an independent sculptor and licensed for commercial printing. The original is linked on this page.
