Extol drill clamp dremel converter
- Arrives in 2 to 7 business days Printed in Auckland. $10 shipping, free over $75
- 14-day faulty refund If it arrives broken or misprinted, we reprint or refund it
- Secure checkout Card payments handled by Stripe
- Material
- High-Detail Resin (8K)
- Colour
- Grey
- Weight
- ~20 g
- Print time
- ~1.1 h
- Express shipping
- $20
More information
This is a clamp for the extol mini drill to extend the diameter to a standard drill so it can be used in a dremel. Since the clamp is standard drill size it should be compatible with any drill stand that can hold a standard drill (just for reference I have been using with this drill stand).
In addition I also made a foot that can be printed in TPU (I used A90) so the stand does not slip (I dont screwed it to the table so it is more mobile).
Printing
This print will need support but assuming the printer can do a decent overhangs the collar does not need support (it has a chamfer). Parts are oriented in the correct way.
I recommend adding 5-6 walls to make the part strong and increase infill (I used gyroid with 35%).
Assembly
It is very easy to assemble, basically it needs 4 M3 screes (18mm will probably do, the hole length is 15mm) and nuts.
Other
I also added the Fusion files if someone wants to tweak it.
Design and description by Abász , licensed CC-BY.
Frequently asked
How long does shipping take?
Extol drill clamp dremel converter is printed to order. Lead time is typically 1-3 business days plus 1-4 days NZ shipping. Standard NZ shipping is $10, free over $75.
What material is this printed in?
By default this is printed in High-Detail Resin (8K) at 0.025 mm layer height on an MSLA resin printer. Custom material and colour swaps are available, just leave a note at checkout.
Can I get this in a different colour?
Yes. Every product can be printed in any of the resin colours we stock, or hand-painted on request. Leave a note at checkout or email [email protected].
Do you ship outside of New Zealand?
Currently New Zealand only. Australian shipping is coming.
Who designed this?
Designed by an independent sculptor and licensed for commercial printing. The original is linked on this page.
