Pin Header Snapping Tool - Single Row - 2.54mm Pitch
- Arrives in 2 to 7 business days Printed in Auckland. $10 shipping, free over $75
- 14-day faulty refund If it arrives broken or misprinted, we reprint or refund it
- Secure checkout Card payments handled by Stripe
- Material
- High-Detail Resin (8K)
- Colour
- Grey
- Weight
- ~19 g
- Print time
- ~1 h
- Express shipping
- $20
More information
Inspired by several similar tools, I wanted to create my own, using laser cut acrylic. Works with any break-away, single row, 2.54mm male header pins, regardless of length, even right-angle headers.
Inspiration:
• Break-Away Header Pin Snapper Tool by Proto-Pic • RedSnapper - The Compact and Precise Pin Header Adjustment Tool - 2.54mm Pitch by phenoptix • Pin Header Break Away Tool by arturo182
The whole thing took only a few minutes to design in Fusion360, even less to cut and assemble.
The three pieces are assembled together using M2 screws. I screwed them in from the bottom so that I could use this with even right-angle headers.
I'm sure it could be 3D printed, but I haven't tried it, and you might need to adjust the dimensions to suit your printer's tolerance.
I've included DXF files for laser cutting, STL files for 3D printing (although I haven't extruded/embossed the marks or numbers), and the Fusion360 file. The f3d file is parameterized, so hopefully adjusting for tolerance should be easy.
Design and description by Jason Coon , licensed CC-BY.
