Desk Organizer Clamp

This desk organizer is designed to help you organize your maker space without taking up space on the desk itself. Simply print the parts, and clamp it to your desk or table. It's extremely stable and does not move once fixed in place. Leave a like :D

Assembly Instructions:

You will need to print:

1 x Holder

2 x wing bolt

2 x wing nut

First, insert each bolt through the holes at the bottom of the holder. Next, thread the wing bolts on but don't tighten it yet. Leave some space for it to mount to the table. Then, afix the holder to the spot that you want to mount it to. Finally, tighten the wing bolts by hand. If you have trouble holding the wing nuts in place, there are a few grooves near the holes on the other side of the holder. You should be able to use them to stop the nuts from moving while you tighten the bolts.

Print Instructions: (I use a Flashforge Adventurer 3 pro)

Holder: Print in the orientiation shown in photo

• Print speed: 60mm/s - 80mm/s • Layer height: 0.25mm • Shells: 2 • 5% infill • Supports are optional for the holes • Brim is optional • No raft

Wing Bolt and Nut:

• Print speed: 60mm/s • Layer height: 0.16mm • Shells: 2 • 25% infill • No supports • Brim is optional • No raft

Design and description by Vioppoiv , licensed CC-BY.
