Go Pro Arca Swiss Mount
- Arrives in 2 to 7 business days Printed in Auckland. $10 shipping, free over $75
- 14-day faulty refund If it arrives broken or misprinted, we reprint or refund it
- Secure checkout Card payments handled by Stripe
- Material
- High-Detail Resin (8K)
- Colour
- Grey
- Weight
- ~9 g
- Express shipping
- $20
More information
I use Arca-Swiss compatible heads on my tripods and wanted the ability to mount my GoPro Hero7 easily without hassle.
At the time of designing this I couldn't find any other alternatives that mad me happy.
An additional M5 (0.8mm pitch thread) nut (preferably a Cap Nut) is required to allow the mount to be attached to the GoPro correctly.
This nut should be a push/pressure fit, but for added peace of mind I adhered mine with two-part epoxy.
If you are not using the bolt that came with the GoPro then an appropriate substitute must also be sourced.
Print instructions
• Printed in PETG
• 0.1mm layer height
• Cubic infill @ 20%
• 4 perimeters
Design and description by bigshum , licensed CC0.
More 3D printed GoPro mountsMore 3D printed camera and tripod mounts
Frequently asked
How long does shipping take?
Go Pro Arca Swiss Mount is printed to order. Lead time is typically 1-3 business days plus 1-4 days NZ shipping. Standard NZ shipping is $10, free over $75.
What material is this printed in?
By default this is printed in High-Detail Resin (8K) at 0.025 mm layer height on an MSLA resin printer. Custom material and colour swaps are available, just leave a note at checkout.
Can I get this in a different colour?
Yes. Every product can be printed in any of the resin colours we stock, or hand-painted on request. Leave a note at checkout or email [email protected].
Do you ship outside of New Zealand?
Currently New Zealand only. Australian shipping is coming.
Who designed this?
Designed by an independent sculptor and licensed for commercial printing. The original is linked on this page.
